MCP server examples: local, remote, and multi-app
Three MCP server examples that show when to use a local stdio server, a protected remote server, or a hosted multi-app connector.
An MCP server can be a small local program, a remote service for a team, or a hosted connector that exposes many apps. The protocol is shared, but the place where it runs determines who manages credentials, networking, updates, and availability.
Example 1: a local filesystem server
A coding agent starts a filesystem MCP server on the same machine over stdio.
The server exposes tools such as reading a file, listing a directory, or writing
a generated file. The host launches the process and communicates through its
standard input and output streams.
Use this pattern when the tools need local files or a private development environment. The operator owns the process, its permissions, and its updates.
Example 2: a remote internal-data server
An organization runs a remote MCP server over Streamable HTTP. It exposes a small set of tools that query an internal system, such as a customer database or deployment status service. Each user signs in before their agent can call it.
Use this pattern when the API is private and access rules belong to the company. The server must validate incoming tokens and give its upstream systems separate credentials. See MCP server authentication for the difference between those credentials.
Example 3: a hosted multi-app connector
A person connects Gmail, Notion, or Google Drive in a browser. A hosted service runs the provider OAuth flow, retains the account connection, and exposes the supported actions to the agent as MCP tools. The person does not build an OAuth app or operate a refresh-token job for every provider.
Use this pattern for standard SaaS apps when a third-party connection path is acceptable. ClawLink is this type of service for its supported catalog. It is not a replacement for a server that must reach an internal network or expose a custom company API.
How to choose
| Need | Best starting pattern |
|---|---|
| Read or change files on one machine | Local stdio server |
| Reach a company-only API | Remote internal server |
| Connect common SaaS accounts | Hosted multi-app connector |
| Change tool behavior or call a private network | Self-hosted server |
| Avoid operating provider OAuth and token refresh | Hosted connector |
The official MCP architecture allows both local and remote servers. “Remote” does not mean “hosted connector,” and “self-hosted” does not mean “more permissions.” Those labels describe operation and network placement; provider scopes still decide what a tool can do.
